Magnetic Plate, Ceramic, L 9 1/8xW11 1/2In
| Magnetic Separator Type | Plate Magnet |
|---|---|
| Primary Magnet Material | Ceramic |
| Maximum Magnetic Pull Strength | 70 oz |
| Magnetic Intensity | 1,950 G |
| Overall Length | 9-1/8 in |
| Overall Width | 11-1/2 in |
| Overall Height | 2 1/16 in |
| Item | Plate Magnet |
| Cutout Length (In.) | 7-5/8 |
| Housing Material | 304 Stainless Steel |
| Width (In.) | 11-1/2 |
| Max. Operating Temp. | 400 deg F |
| Frame Material | Stainless Steel |
| Max. Pull on Contact | 70 Ounces At 3/4" Gap With 1/8" Thick X 1" Wide X 3" Long Steel Test Plate |
| Cutout Width (In.) | 10 |
| Magnet Housing Material | Stainless Steel |
| Magnet Type | Ceramic |
| Height (In.) | 2-1/16 |
| Length (In.) | 9-1/8 |
| Intensity Range (Gauss) | 1,950 |
| Includes | Handle |
| Temp. Range (F) | 0 to 400 |
| Flange Width (In.) | 11-1/2 |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
