The Federal Pacific NAGF25 is a 1 Pole molded case ground fault circuit breaker with a current rating of 25 Amps and a voltage rating of 120V. It has an interrupting rating of 10kAIC at 120V. The NAGF25 has a plug-in connection type and includes long time and instantaneous trip functions.
| Brand | Federal Pacific |
|---|---|
| Series | NAGF |
| Amperage | 25 |
| Voltage | 120 |
| Poles | 1 |
| Phase | 1 |
| Interrupting Rating | 10kAIC@120V |
| Frame Type | NA |
| Connection Type | Plug-In |
| Protection | Thermal Magnetic |
| Functions | Long Time and Instantaneous |
| Terminal Connection | Load side lug |
| Mpn | NAGF25 |
