The Federal Pioneer NAGF20FED is a 1 Pole molded case ground fault circuit breaker with a current rating of 20 Amps and a voltage rating of 120V. It has an interrupting rating of 10kAIC at 120V. The NAGF20FED has a plug-in connection type and includes long time and instantaneous trip functions.
| Brand | Federal Pioneer |
|---|---|
| Series | Stab-Lok |
| Amperage | 20 |
| Voltage | 120V |
| Poles | 1 |
| Phase | 1 |
| Interrupting Rating | 10kAIC at 120V |
| Connection Type | Plug-In |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous |
| Terminal Connection | Load Side Lug |
| Circuit Breaker Type | GFCI |
| Mpn | NAGF20FED |
