Warning Light, Strobe Tube, Red, 120VAC
| Item | Warning Light |
|---|---|
| Color | Red |
| Lamp Type | Strobe Tube |
| Power Source | Wire |
| Lamp Life | 4,000 hr |
| Lens Material | Polycarbonate |
| Flashes per Minute | 80 |
| Height | 4 in |
| Housing Material | Polycarbonate |
| Standards | CSA Certified, cULus Listed, UL Listed |
| Features | Conformal Coated PCBA |
| Operating Temp. | -31 to 150 deg F |
| Lens Design | Screw-on Dome |
| Light Output | 108,000 Candela |
| Depth | 1-5/8 in |
| Current Drawn | 0.06A AC |
| Voltage | 120 |
| Mounting | Surface |
| Width | 4 in |
| Rating | IP44, NEMA 3R |
| For Use With | Security, Control Panel, Indoor, Industrial, Outdoor |
| Product Type | Strobe Light |
| Audible Alarm Type | Visual |
| Connection Type | Not Applicable |
| NEMA Rating | NEMA 3R |
| Lens Color | Red |
| Overall Width | 3-15/16 in |
| Overall Length | 3-15/16 in |
| Light Operating Mode | Strobe |
| Mounting Mechanism | Not Applicable |
| Mounting Style | Surface Mount |
| Runtime | Not Applicable |
| Requires Base | Base Not Required |
| Footprint Width | Not Applicable |
| Operating Current | 0.060 A @ 120V AC |
| Battery Size | Not Applicable |
| Overall Diameter | Not Applicable |
| Operating Temperature - Maximum | 150 deg F |
| Lamp Color | Not Applicable |
| Brightness Selection | Fixed Brightness |
| Light Intensity | 108,000 cd |
| Includes Mounting Hardware | Not Applicable |
| For Location | Indoor, Outdoor |
| Footprint Diameter | Not Applicable |
| Footprint Shape | Not Applicable |
| For Hazardous Location | Not Applicable |
| Operating Temperature - Minimum | -31 deg F |
| Overall Depth | 1-19/32 in |
| Number of Batteries | Not Applicable |
| Lifespan | 4,000 hr |
| Control Protocol | Direct Wire |
| Footprint Length | Not Applicable |
| IO-Link Compatibility | Not Applicable |
| Includes Batteries | Not Applicable |
| IP Rating | IP44 |
| Lens Shape | Dome |
| Light Source | Not Applicable |
| Operating Voltage | 120V AC |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
