DC Power Supply, 24V AC, 1.5 to 14V DC, 300 mA, Track
| Item | DC Power Supply |
|---|---|
| Input Voltage | 24V AC |
| Output Voltage | 1.5 to 14V DC |
| Output Amps | 300 mA |
| Mounting | Track |
| Height | 4 in |
| Width | 2-3/4 in |
| Depth | 1-3/4 in |
| Hz | 50/60 Hz |
| Operating Temp. Range | -30 to 140 deg F |
| Humidity Range | 5 to 95% (noncondensing) |
| Regulation | Load: 0.04% No Load to Full Load Line: 0.0080 mV/V |
| Power Status | LED On - Activated |
| Overload Protection | Electrical and Thermal, Auto-Reset |
| Frequency | 50/60 Hz |
| Percent Ripple | 0.0016%, 12 Vdc @ 300 mA |
| Track Mount | 4.000" and 2.750" |
| ON/OFF Switch | 2 Position |
| Approvals | Class 2, UL916, C-UL, CE |
| Output Current Ratings | 300 mA @ 12 Vdc |
| Package Quantity | 1 |
