DC Power Supply, 24V AC, 1.5 to 14V DC, 300 mA, Track
| Item | DC Power Supply |
|---|---|
| Input Voltage | 24V AC |
| Output Voltage | 1.5 to 14V DC |
| Output Amps | 300 mA |
| Mounting | Track |
| Height | 1-3/4 in |
| Width | 2-3/4 in |
| Depth | 1-1/2 in |
| Hz | 50/60 Hz |
| Operating Temp. Range | -30 to 140 deg F |
| Standards | CE, RoHS, UL |
| Manufacturers Warranty Length | 5 yr |
| Load Regulation | 0.0004 |
| Line Regulation | 0.625 mV/V, 8 mV/V |
| Ripple | 0.0016%, 24 VDC @ 300 mA, 0.0016%, 24 VDC @ 1A |
| Approvals | Class 2 UL916 listed, ULC, File #E68805 |
| DC Voltage Output Type | Adjustable |
| Input Current | 300 mA |
| Package Quantity | 1 |
