Interruptor de seguridad de un solo tiro no fusible, deber general, 120V CA, 2PST, 10 A, NEMA 1.
| Item | Single Throw Safety Switch |
|---|---|
| Protection Method | Nonfusible |
| Duty | General |
| Voltage | 120V AC |
| Phase | 1 |
| NEMA Enclosure Type | 1 |
| IP Rating | 20 |
| Number of Wires | 2 |
| Number of Poles | 2 |
| Contact Form | 2PST |
| Amps AC | 10 A |
| Metallic / Non-Metallic | Non-Metallic |
| Material of Construction | Plastic |
| Width | 4 in |
| Height | 4 in |
| Standards | C-UL, CE, RoHS, UL916 |
| Depth | 1.8 in |
| Fusible / Nonfusible | Nonfusible |
| Includes | Circuit Breaker, Switch and 2 Outlets |
| Approvals | UL Listed, UL916, C-UL, CE |
| Operating Temperature | -30 to 140° F |
| Housing Rating | UL Accepted for Use in Plenum, NEMA 1 |
| Humidity Range | 5 to 95% (noncondensing) |
| Dimensions | 4.00"H x 4.00"W x 1.81"D with 0.50" NPT nipple |
| Circuit Breaker | 10 Amps |
| Package Quantity | 1 |
