Arrancador magnético NEMA sin inversión, 1 Clasificación NEMA, 480V CA, 3 Polos, 1NC.
| Item | NEMA Magnetic Motor Starter |
|---|---|
| Overload Relay Amp Setting | 6.5 to 13.5 A |
| Coil Volts | 480V AC |
| Enclosure NEMA Rating | 1 |
| Auxiliary Contact Form | 1NO |
| HP @ 3 Phase - 240V | 1.5 HP |
| Starter Type | NEMA Style |
| Action | Nonreversing |
| Amps AC | 6.5 to 13.5 |
| NEMA Size | 1 |
| Number of Poles | 3 |
| HP @ 3 Phase - 480V | 10 HP |
| HP @ 1 Phase - 120V | 2 hp |
| Standards | CSA, UL Listed |
| Hz | 50/60 |
| HP @ 3 Phase - 575V | 10 hp |
| Height | 7 in |
| Width | 3.71 in |
| Features | Tool less Coil Change, Quick Contact Inspection, Wiping Magnet Surfaces for Longer Wear |
| Depth | 3.94 in |
| Includes | Holding Interlock, Pressure Terminals |
| HP @ 3 Phase - 208V | 7.5 HP |
| HP @ 1 Phase - 230V | 3 hp |
| Thermal Unit Code | Not Applicable |
| Phase | Three |
| Minimum Overload Relay Current Setting | 6.5 A |
| Overall Depth | 6 in |
| Includes Auxiliary Contacts | Yes |
| Horsepower @ Three Phase - 240V AC | 1.5 HP |
| Mounting Hole Distance - Height | 8 in |
| Series | CR306 |
| Frequency | 50/60 Hz |
| Overload Protection Type | Electronic |
| Number of Auxillary Contacts | 1 |
| Maximum Voltage Rating | 480 V AC |
| Coil Voltage | 480V AC |
| Minimum Operating Temperature | -4 deg F |
| Mounting Hole Distance - Width | 4 in |
| Starter Style | NEMA |
| Overall Width | 4.63 in |
| Overall Height | 10 in |
| Resistance Properties | Weld Resistant |
| Maximum Overload Relay Current Setting | 13.5 A |
| Current AC | 27 A |
| Horsepower @ Three Phase - 480V AC | 10 HP |
| Reversing Capability | Non-Reversing |
| Mounting Style | DIN Rail |
| NEMA Enclosure Rating | 1 |
| Horsepower @ Three Phase - 600V AC | 10 HP |
| Horsepower @ Single Phase - 120V AC | 2 HP |
| Horsepower @ Three Phase - 208V AC | 7.5 HP |
| Maximum Operating Temperature | 158 deg F |
| Package Quantity | 1 |
