Arrancador de motor magnético NEMA no reversible, sin gabinete de clasificación NEMA, 120V CA, 3 polos, 1NC.
| Item | NEMA Magnetic Motor Starter |
|---|---|
| Overload Relay Amp Setting | 25 to 50 A |
| Coil Volts | 120V AC |
| Enclosure NEMA Rating | No Enclosure |
| Auxiliary Contact Form | 1NO |
| HP @ 3 Phase - 240V | 15 HP |
| Starter Type | NEMA Style |
| Action | Nonreversing |
| Amps AC | 25 to 50 |
| NEMA Size | 2 |
| Number of Poles | 3 |
| HP @ 3 Phase - 480V | 25 HP |
| Includes | Holding Interlock, Pressure Terminals |
| Features | Tool less Coil Change, Quick Contact Inspection, Wiping Magnet Surfaces for Longer Wear |
| Width | 5.44 in |
| Depth | 5-1/2 in |
| HP @ 3 Phase - 208V | 10 HP |
| Hz | 50/60 |
| Height | 9.12 in |
| Standards | CSA, UL Listed |
| Thermal Unit Code | Not Applicable |
| Phase | Three |
| Mounting Hole Distance - Height | 8-1/2 in |
| Maximum Voltage Rating | 120 V AC |
| Overall Height | 9.12 in |
| Number of Auxillary Contacts | 1 |
| Resistance Properties | Weld Resistant |
| Overall Width | 5.44 in |
| Horsepower @ Three Phase - 240V AC | 15 HP |
| Minimum Operating Temperature | -4 deg F |
| Mounting Style | DIN Rail |
| Horsepower @ Three Phase - 208V AC | 10 HP |
| Reversing Capability | Non-Reversing |
| Series | CR306 |
| Frequency | 50/60 Hz |
| NEMA Enclosure Rating | No Enclosure |
| Includes Auxiliary Contacts | Yes |
| Mounting Hole Distance - Width | 2 in |
| Coil Voltage | 120V AC |
| Overall Depth | 5-1/2 in |
| Current AC | 45 A |
| Maximum Overload Relay Current Setting | 50 A |
| Overload Protection Type | Electronic |
| Minimum Overload Relay Current Setting | 25 A |
| Starter Style | NEMA |
| Maximum Operating Temperature | 158 deg F |
| Horsepower @ Three Phase - 480V AC | 25 HP |
| Package Quantity | 1 |
