The General Electric TEYH2070B is a 2 Pole thermal magnetic molded case circuit breaker with a current rating of 70 Amps and a voltage rating of 277/480VAC, 250VDC. It has an interrupting rating of 35kAIC at 277/480VAC. The TEYH2070B has a bolt-on connection type and includes LI - long-time and instantaneous trip functions.
| Brand | General Electric |
|---|---|
| Series | TEY |
| Amperage | 70 |
| Voltage | 277/480VAC, 250VDC |
| Poles | 2 |
| Phase | 1 |
| Mounting Type | Bolt On |
| Approval | UL |
| Interrupting Rating | 35kAIC at 277/480VAC |
| Frame Type | TEY |
| Connection Type | Bolt On |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous |
| Terminal Connection | Load Side Lug |
| Length (in) | 3 |
| Width (in) | 2 |
| Height (in) | 5.2 |
| For Use With | AS lighting panels |
| Temperature Rating | 40 °C |
| Circuit Breaker Type | Standard |
| Actuator Type | Toggle |
| Max Wire Size | 2 AWG |
| Min Wire Size | 4 AWG |
| Upc | 783164462050 |
| Gtin | 783164462050 |
