The General Electric THQL2140GF is a 2 Pole molded case ground fault circuit breaker with a current rating of 30 Amps and a voltage rating of 240VAC. It has an interrupting rating of 10kAIC at 120V. The THQL2140GF has a plug-in connection type and includes long time and instantaneous trip functions.
| Brand | General Electric |
|---|---|
| Series | THQL |
| Amperage | 30 |
| Voltage | 240VAC |
| Poles | 2 |
| Phase | 1 |
| Approval | UL |
| Interrupting Rating | 10kAIC at 120V |
| Connection Type | Plug-In |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous Trip |
| Terminal Connection | Load Side Lug |
| Circuit Breaker Type | GFCI |
| Mpn | THQL2140GF |
| Upc | 78316405998 |
| Gtin | 783164059984 |
