CAT40 600 DA100 Collet Chuck
| Shank Type | Taper |
|---|---|
| Uses Collet Series | Double Angle |
| Taper Size | CAT40 |
| Collet Series | DA100 |
| Min. Collet Capacity | 3/64 in |
| Max. Collet Capacity | 9/16 in |
| Projection | 6 in |
| Nut Dia. | 1.06 in |
| Balanceable | 20,000 |
| Features | DIN coolant thru the flange, All Ground Body, CAT40 Premium balanced to 20,000 rpm, CAT50 Premium balanced to 15,000 rpm. |
| Seat Depth | 1.15 in |
| Package Quantity | 1 |
