Corner Chamf. End Mill, 6.00mm Dia, Carb.
| Item | Chamfer Mill |
|---|---|
| Number of Flutes | 4 |
| Overall Length | 58 mm |
| Shank Dia. | 6 mm |
| Length of Cut | 13 mm |
| End Mill Style | Chamfer Mill |
| Single End/Double End | Single End |
| Cast Iron (K) Compatibility | Yes |
| End Mill Application | Roughing/Finishing |
| Grade | General Purpose |
| Cutting Direction | Right Hand |
| Milling Dia. | 6 mm |
| Helix Angle | 43 deg |
| List Number | F1004NN |
| Dimension Type | Metric |
| Milling Diameter | 6 mm |
| Shank Type | Straight |
| Neck Dia. | 5.7 mm |
| Neck Length | 7 mm |
| Chamfer Width | 0.2 mm |
| Chamfer Angle | 45 deg |
| End Mill Cutting Type | Center Cutting |
| Stainless (M) Compatibility | Yes |
| Steel (P) Compatibility | Yes |
| Hardened (H) Compatibility | No |
| Non Ferrous (N) Compatibility | Yes |
| End Mill Material | Carbide |
| Finish | AlTiN |
| Super Alloy (S) Compatibility | No |
| Included Angle | 45 deg |
| Material Grade - Machining | General Purpose |
| Shank Type - Machining | Straight |
| Finish - Machining | AlTiN |
| Measurement System | Metric |
| Drilling Tool Configuration | Individual |
| Package Quantity | 1 |
