ABS Electrical Enclosures, 6.3 in H, 2.36 in D, 5.12 in W, NEMA 4, 4X, 12, 13, Screw On
| Item | Electrical Enclosures |
|---|---|
| Nominal Width | 5.12 in |
| Nominal Height | 6.3 in |
| Nominal Depth | 2.36 in |
| Enclosure NEMA Rating | NEMA 4, 4X, 12, 13 |
| Material of Enclosure | ABS |
| Closure Method | Screws |
| Enclosure Cover Type | Screw On |
| Metallic / Non-Metallic | Non-Metallic |
| Color | Light Gray |
| Finish | Textured |
| Solid / Clear Cover | Solid |
| IP Rating | IP66 |
| Standards | Meets NEMA Type 4, 4X, 12 and 13; Meets IP66; ABS Plastic material: UL94 V-0 1.6mm flammability Rating |
| Application | ABS fire retardant plastic enclosures are designed for use as instrument enclosures, electrical junction boxes or terminal wiring enclosures where metallic enclosures are not suitable; Modern design with rounded edges & hidden assembly screws; Provide outstanding protection against dust, oil and pressurized water; Impervious to atmospheric and marine corrosion. |
| Flame Rating | UL94 V-0 |
| Package Quantity | 1 |
