Han Ess 10 Pos. M Insert se traduce como: Ensamble Hembra de 10 Posiciones, Montaje en Panel.
| Color | Pebble Gray |
|---|---|
| Min. Single Wire Size | 26 AWG |
| Max. Single Wire Size | 14 AWG |
| Series | Han ESS |
| Max. Voltage | 500 V |
| Sub-Category | Inserts |
| Approximate Amperage Rating - Grounding Braid | 16 A |
| Standards | EN 45545-2 (2020-08); DNV GL; UL 1977 ECBT2.E235076; CSA-C22.2 No. 182.3 ECBT8.E235076 |
| Terminal Type | Clamp |
| Finish | Silver Plated |
| Green Environmental Attribute | Pollution Degree 3 |
| Connection Material | Copper Alloy |
| Description/Special Features | Two Terminations per Contact |
| Item | Contact Insert |
| Material | Polycarbonate |
| Connector Type | Male |
| Max. Temp. | 125 deg C |
| Number of Contacts | 10 |
| Contact Finish | Silver Plated |
| Current Rating | 16 A |
| Flammability Rating | UL 94 V-0 |
| Package Quantity | 1 |
