Direct Acting 60F To 90F Throttling R
| Item | Pneumatic Thermostat |
|---|---|
| Sensor Type | Bi-Metallic Spring |
| Overall Width | 2 in |
| Throttling Range | 2 Degrees to 10 Degrees F |
| Application | Heat Only |
| Control Type | Exposed Dial |
| Overall Height | 3-1/4 in |
| Air Consumption | 19 scim |
| Includes | Mounting Plate |
| Maximum Control Temperature | 100 deg F |
| Number of Dials | Single |
| Temperature Control Range | 59 to 90 deg F |
| Manual Indexing Switch | No |
| Differential Type | Adjustable |
| Action | Direct |
| Overall Depth | 1-5/8 in |
| Number of Pipes | 2 |
| Temperature Scale | Fahrenheit |
| Thermostat Action | Direct |
| Temperature Settings | Single Temperature |
| Compatible System Type | Pneumatic Valves and Damper Actuators |
| Mounting Direction/Includes Cover | Vertical, Yes |
| Maximum Air Pressure | 25 psig |
| Number of Pipes/Air Flow Output | 2 Pipes, High Volume |
| Air Flow Output | High Volume |
| Mounting Direction | Vertical |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
