Electric Actuator, 25 in.-lb., 24VAC
| Spring Return | Spring Return |
|---|---|
| Signal Type | Floating Point |
| Torque | 25 in-lb |
| Voltage | 24V AC |
| Width | 5 in |
| Stroke Deg. | 90 |
| Shaft Type | Single-Ended |
| Item | Actuator |
| Ambient Temp. Range | -25 to 125 deg F |
| Electrical Connections | Quick-Connect Terminals |
| Motor Direction | CCW |
| Timing | 90 sec |
| Depth | 5-3/16 in |
| Power Consumption | 3 VA |
| For Use With | Combustion Air Dampers Used In Residential or Commercial HVAC Equipment, Control of Economizer Systems, Ventilation Dampers |
| Height | 4-1/2 in |
| Standards | UL 94-5V |
| Application | Dampers, Valves |
| Input Voltage | 24V AC |
| Overall Width | 4-1/2 in |
| Overall Height | 5 in |
| Stroke Degree | 90 Degrees |
| IP Rating | Not Applicable |
| Rated Torque | 25 in-lb |
| Contact Form | SPST |
| Time to Close | 90 sec |
| Electrical Connection Type | Hardwired |
| Number of Auxiliary Switches | 0 |
| NEMA Rating | Not Applicable |
| Overall Depth | 5-1/4 in |
| Maximum Operating Temperature | 125 deg F |
| Product Type | Damper Actuator |
| Output Signal | Not Applicable |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Valve Application | Damper |
| Shaft Rotation | CCW |
| Minimum Operating Temperature | -25 deg F |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
