La cabeza del interruptor de límite Wbbl Stick, superior, ofrece un rendimiento confiable con 2 contactos normalmente abiertos y 2 contactos normalmente cerrados. Ideal para aplicaciones industriales.
| Item | Limit Switch Head |
|---|---|
| Actuator Style | Rotary Lever |
| Actuator Location | Side |
| Actuator Length | Not Specified |
| Contact Form | 2NC, 2NO |
| For Use With | Mfr. No. LSM6D |
| NEMA Rating | 1, 3, 4, 4X, 6, 6P |
| Movement | CCW, CW |
| Travel | Pretravel 18 Degrees Max., Overtravel 57 Degrees Min., Differential Travel 10 Degrees Max. |
| Standards | RoHS |
| Voltage Rating | 600V AC / 250V DC |
| Amps | 10 |
| Operating Temp. | 30 to 250 deg F |
| IP Rating | Not Rated |
| AC Contact Rating | 10 A @ 600 V |
| Operating Force | Not Applicable |
| Roller Material | Not Applicable |
| Arm Depth | Not Applicable |
| Roller Width | Not Applicable |
| Differential Travel | Not Applicable |
| Arm Width | Not Applicable |
| Arm Material | Not Applicable |
| Type | Heavy Duty Plug-In Limit Switch Body |
| Head Action | Spring Return, Standard |
| Roller Position | Not Applicable |
| Compatible with Brand | Honeywell |
| Arm Length - Maximum | Not Applicable |
| Operating Temperature - Minimum | 30 deg F |
| Plunger Adjustability | Not Applicable |
| Reset Travel | Not Applicable |
| Arm Length - Minimum | Not Applicable |
| Compatible with Manufacturer Model Number | LSM6D |
| Roller Adjustability | Not Applicable |
| NEMA Enclosure Rating | 1, 3, 4, 4X, 6, 6P |
| Pretravel | Not Applicable |
| Arm Adjustability | Not Applicable |
| Directional Movement | CCW, CW |
| Roller Diameter | Not Applicable |
| Operating Temperature - Maximum | 250 deg F |
| Action | Not Applicable |
| Compatible with Series | LS |
| Series | HDLS |
| Overtravel | Not Applicable |
| Total Travel | Not Applicable |
| Operating Torque | Not Applicable |
| Compatible Manufacturer Part Number | LSM6D |
| Compatible Manufacturer Model Number | LSM6D |
| Compatible with Mfr. Model No. | LSM6D |
| For Use with Mfr Model Number | LSM6D |
| For Use With Mfr. Model Number | LSM6D |
| Package Quantity | 1 |
