DL380 G10+ 4314 MR416i-a N
| Item | Server |
|---|---|
| Width | 17-1/2 in |
| Includes | ProLiant DL380 G10 Plus Server 6-foot IEC C-13/C-14 Jumper Cord |
| Depth | 28 in |
| Input Voltage | 120 V AC, 230 V AC |
| Height | 3.4 in |
| Number of Power Supplies Installed | 2 |
| Number of Network (RJ-45) Ports | 2 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Processor Speed | 2.4 GHz |
| Hot Swappable Power Supply | Yes |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 800 W |
| Solid State Drive Configuration | (2) 480GB |
| Environmentally Friendly | Yes |
| Power Source | Power Supply |
| Hot Swappable Bays | Yes |
| VGA | Yes |
| Cache | 24 MB |
| Graphics Memory Capacity | 16 MB |
| Plug/Connector Type | C14, C13 |
| Number of Processors Installed | 1 |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| Chipset Model | C621A |
| Number of Total Expansion Bays | 8 |
| Intel Optane Memory Ready | Yes |
| Signal Processing | Registered |
| Solid State Drive Interface | Serial ATA |
| Number of Occupied Memory Slots | 4 |
| Redundant Power Supply | Yes |
| Energy Star | Yes |
| Number of Power Supplies Supported | 2 |
| Remote Management Controller | HPE iLO 5 |
| Processor Core | Hexadeca-core |
| Number of USB 3.0 Ports | 5 |
| RAID Supported | Yes |
| Number of VGA Ports | 1 |
| Processor Model | 4314 |
| Total Solid State Drive Capacity | 960 GB |
| Controller Type | Serial ATA, NVMe, 12Gb/s SAS |
| Remote Management | Yes |
| Total Number of Expansion Slots | 3 |
| Number of Processors Supported | 2 |
| Memory Technology | DDR4 SDRAM |
| Controller Model | MR416i-a Gen10, Plus |
| Total Number of USB Ports | 5 |
| PCI Express Details | 3 PCIe: PCIe 4.0 X(8)16 Full-height,full-length slot; PCIe 4.0 X1(6)16 Full-height,full-length slot ; PCIe 4.0 X(8)16 Full-height,half-length slot |
| Processor Generation | 3rd Gen |
| Processor Type | Xeon Silver |
| Maximum Memory Supported | 2 TB |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Rack Height | 2 U |
| Number of Solid State Drives | 2 |
| Standard Memory | 128 GB |
| Series | DL380 G10 Plus |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
