15A Duplex Decorator Receptacle 125VAC 5-15R BL
| Item - Plugs and Receptacles | Receptacle |
|---|---|
| Outlet Type - Plugs and Receptacles | Decorator Duplex |
| Application Environment | Commercial |
| Mounting Type - Plugs and Receptacles | Flush |
| Amps - Plugs and Receptacles | 15 A |
| Voltage - Plugs and Receptacles | 125V AC |
| NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| Surge Suppression | Yes |
| Tamper Resistant | No |
| Number of Wires | 3 |
| HP | 1/2 hp |
| Wiring Method - Plugs and Receptacles | Side |
| Amps | 15 |
| Phase | Single Phase |
| Voltage | 125VAC |
| Standards | CSA Certified C22.2 No. 42, UL 498, UL E2186 |
| Sub-Category | Duplex Receptacles |
| Outlet Type | Decorator |
| Amps - Plugs and Receptacles | 15 |
| Weather Resistant | No |
| Color - Plugs and Receptacles | Blue |
| Power Indicator | Yes |
| Wiring Method | Side |
| Material | Composite |
| Weather Resistant - Plugs and Receptacles | No |
| Mounting Type | Flush |
| Number of Gangs | 1 |
| Number of Poles | 2 |
| Item | Surge Protection Receptacles |
| Corrosion Resistant | No |
| NEMA Configuration | 5-15 |
| Color | Blue |
| Current Rating | 15 A |
| Outlet | Straight Blade |
| Connectivity | Terminal Screws |
| Indicator Type | None |
| Mounting Hardware Material | Mounting Screws |
| Carton Quantity | 10 |
| Operating Temperature | 32 Deg F to 140 Deg F (0 Deg C to 60 Deg C) |
| Type | Duplex |
| Amperage | 15 A |
| Application | Decorator Duplex |
| Response Time | 5 |
| Voltage Rating | 125 V |
| Frequency | 60 Hz |
| Nema Rating | 5-15R |
| Display Size | Standard |
| Series | Specification Grade |
| Brand | Hubbell Wiring Device-Kellems |
| Environmental Rating | Indoor Dry Unless Protected By Additional Means |
| Face Plate Width | 1.3 in |
| NEMA Enclosure Rating | 1 |
| Horsepower Rating | 0.5 HP |
| Face Plate Height | 2.6 in |
| UL 94 Flammability Rating | V-2 |
| AFCI | No |
| Mount Type | Flush |
| Connection Orientation | Straight |
| Polarized | Yes |
| Shrouded | No |
| Overall Depth | 4 in |
| Cover Type | No Cover |
| Includes | Grounding Staple, Mounting Hardware |
| Housing Color | Blue |
| NEMA Receptacle Configuration | 5-15R |
| Grade | Federal Specification |
| Visual Indicator Lights | Power Connected |
| Surge Protection | Yes |
| For Location | Indoor |
| GFCI | No |
| Wire Connection Type | Screw Terminals |
| Maximum Operating Temperature | 140 deg F |
| Flange Type | Non-Flanged |
| Receptacle Type | Duplex |
| Contact Material | Brass |
| Housing Material | Composite |
| Market | Commercial |
| Grounding | Grounded |
| Mount Hole Center-to-Center Height | 3.3 in |
| Minimum Operating Temperature | 32 deg F |
| Includes Mounting Hardware | Yes |
| Contact Design | Tandem Modified Bypass |
| LED | Red |
| Device Base | Nylon |
| ANSI/IEEE | C62.41 (IEEE 587) |
| Terminal Screws | #8-32 Brass |
| Certifications | UL Listed File E2186 |
| Installation Categories | A (Ring Wave), "B" (Unidirectional Impulses) |
| Listed To: | UL Standards 498 Receptacles, Meets UL1449 TVSS |
| Mounting Screws | Zinc-Plated, steel |
| Device Top | Nylon |
| Mounting Strap | .050" Steel-Zinc Coated |
| Voltage/Power Rating | 125V AC |
| Clamping Plate | Brass |
| Receptacle Style | Duplex |
| CSA Certified | To Specification C22.2 No. 42 |
| Receptacle Grade | Standard |
| Grounding Screw | Steel |
| Poles and Wires | 2 Pole, 3 Wire |
| Auto Ground Clip | Stainless Steel |
| Alarm | Visual |
| Power Contact | .031" (.8) Brass |
| Package Quantity | 1 |
