20A Straight Blade Replacement Receptacle 125V
| Item | Spider 20A Straight Blade Replc Rcpt |
|---|---|
| Number of Poles | 2 |
| Number of Wires | 4 |
| Corrosion Resistant | No |
| Wiring Method | Back, Side |
| Standards | CSA Certified, cUL Listed, UL 1640, UL 943 |
| Material | Thermoplastic |
| Number of Gangs | 1 |
| Phase | Single |
| Includes Mounting Hardware | Yes |
| Resistance Properties | Moisture Resistant |
| Face Plate Width | 4.4 in |
| Housing Material | Thermoplastic |
| NEMA Receptacle Configuration | 5-20R |
| Grade | General Use |
| For Location | Indoor |
| Mount Hole Center-to-Center Width | 3.1 in |
| Cover Type | Flip-Up Cover |
| Mount Hole Center-to-Center Height | 3.1 in |
| Number of Outlets | 1 |
| Housing Color | Brown |
| Market | Industrial |
| Voltage Rating | 125V AC |
| GFCI | No |
| Current Rating | 20 A |
| Connection Orientation | Straight |
| Flange Type | Flanged |
| Wire Connection Type | Screw Terminals |
| Grounding | Grounded |
| For Environment | Dry |
| Flange Shape | Square |
| NEMA Enclosure Rating | 3R |
| Mount Type | Flush |
| Minimum Wire Size | 14 AWG |
| Surge Protection | No |
| Polarized | Yes |
| Shrouded | No |
| Maximum Wire Size | 12 AWG |
| Face Plate Height | 4.1 in |
| AFCI | No |
| Replacement Part Type | 20A 125V Straight Blade Receptacle |
| Operation | Indoor and outdoor wet and dry locations |
| Listings and Certifications | UL 1640 cUL and CSA, UL 943 |
| Product Type | spider |
| Enclosure Type | 3R, Rainproof, Suitable for use in damp locations. |
| Amperage Rating | 20 A |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Wattage | 2500 |
| Current / Amperage Rating | 20 A |
| Display Size | Standard Sized Product |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Wire Size | #14 AWG to #12 AWG |
| Voltage Rating Description | 125 VAC |
| Industry Standard(s) | UL 1640 cUL and CSA, UL 943 |
| Connectivity | Back and Side Wired Screw Terminals |
| Material - Mounting Hardware | Screw Mounting |
| Style | Receptacle |
| Type | Replacement Part |
| Item Type | Single |
| Application | Heavy Duty Industrial |
| Package Quantity | 1 |
