3 Wire Industrial Straight Blade Plug 125/250VAC 20A
| Item - Plugs and Receptacles | Straight Blade Plug |
|---|---|
| Item | Straight Blade Plug |
| Wiring Style | Standard |
| Grade - Plugs and Receptacles | Industrial |
| Amps - Plugs and Receptacles | 20 A |
| Voltage - Plugs and Receptacles | 125/250V AC |
| NEMA Plug Configuration - Plugs and Receptacles | 10-20P |
| Number of Wires | 3 |
| Phase - Plugs and Receptacles | 3 |
| Antimicrobial | No |
| Color | Black, White |
| Number of Poles | 3 |
| Corrosion Resistant | Yes |
| Grade | Industrial |
| Boot Code | A |
| HP | 1.0 Line to Neutral, 2.0 Line to Line |
| Cord Size | 0.385 to 0.78 in |
| Phase | Single |
| Voltage | 125/250VAC |
| Special Features | Corrosion resistant |
| Color - Plugs and Receptacles | Black, White |
| IP Rating | IP20 |
| Amps | 20 |
| Material | Nylon |
| Standards | CSA Certified, UL Listed |
| NEMA Rating | 10-20P |
| Voltage Rating | 125/250V AC |
| For Maximum Cable Diameter | 0.78 in |
| Wire Connection Type | Screw Terminals |
| Polarized | Yes |
| Outside Diameter | 1.94 in |
| Insulation Material | Nylon |
| Number of Blades | 3 |
| Market | Industrial |
| Horsepower Rating | 1 HP, 2 HP |
| Housing Color | Black |
| Connection Orientation | Straight |
| Current Rating | 20 A |
| For Minimum Cable Diameter | 0.385 in |
| NEMA Plug Configuration | 10-20P |
| Body Length | 2-1/2 in |
| Resistance Properties | Corrosion Resistant |
| Housing Material | Nylon |
| Grounding | Non-Grounded |
| Contact Blades Material | .075 Brass |
| Retainer Material | Polycarbonate |
| Terminal Screw Material | Brass, Ni Plated |
| Flammability | UL 94 HB or better. |
| Weight (Lbs.) | 0.3 |
| Dielectric Strength | Withstands 2,000V minimum |
| Cord Clamp Material | Nylon |
| Temp. Rise | Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%.. |
| Body Style | Straight |
| Operating Temp. | Maximum continuous 75°C; minimum 40°C (w/o impact); Maximum continuous 75°C, minimum -40°C (w/o impact). |
| Blade Holder Material | Nylon |
| Package Quantity | 1 |
