50A Flanged Inlet Single Receptacle 3P 4W 125/250V
| Item | Watertight Locking Receptacle |
|---|---|
| NEMA Configuration | Non-NEMA |
| Voltage | 125/250V AC |
| Amps | 50 |
| Color | Gray |
| Number of Poles | 3 |
| Number of Wires | 4 |
| Phase | Single |
| Shrouded / Non-Shrouded | Shrouded |
| Wiring Style | Standard |
| IP Rating | IP67 |
| Standards | CSA Certified C22.2 No. 42, UL 498 |
| NEMA Rating | 4x |
| Special Features | With Cover |
| Material | Valox |
| Mounting Type | Flush Mount |
| Grade | Industrial |
| Voltage Rating | 125/250V AC |
| NEMA Receptacle Configuration | Non-NEMA |
| Minimum Operating Temperature | -40 deg C |
| UL 94 Flammability Rating | V-0 |
| Flange Shape | Rectangular |
| Maximum Operating Temperature | 75 deg C |
| Market | Industrial |
| Housing Material | Steel, Zinc Plated |
| Maximum Wire Size | 6 AWG |
| Resistance Properties | Heat Resistant |
| Connection Orientation | Straight |
| Polarized | Yes |
| Mount Type | Flush |
| Shrouded | Yes |
| Flange Type | Flanged |
| For Environment | Dry |
| Wire Connection Type | Screw Terminals |
| NEMA Enclosure Rating | 4X |
| Cover Type | No Cover |
| For Location | Indoor |
| Housing Color | Black |
| Current Rating | 50 A |
| AFCI | No |
| Minimum Wire Size | 10 AWG |
| Number of Gangs | 1 |
| Flammability | UL 94 V0 |
| Weight | 0.8 lb |
| Dielectric Strength | 2,000 V |
| Cord Size | 10 to 6 AWG |
| Operating Temp. | -40 to 75°C |
| Wire Size | #10 AWG to #6 AWG |
| Height | 3-3/4 in |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Current / Amperage Rating | 50 A |
| Voltage Rating Description | 125/250 V |
| Application | Industrial |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Item Type | Flanged Single Male |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Amperage Rating | 50 A |
| Length | 3.8 in |
| Dimensions | 3.8 in x 3.43 in x 3-3/4 in |
| Style | Inlet |
| Type | Replacement Part |
| Width | 3.43 in |
| Industry Standard(s) | Certified to CSA C22.2 No.42 Listed to UL 498 |
| Material - Mounting Hardware | Screw Mounting |
| Display Size | Standard Sized Product |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V0 Environmental - Operating Temperatures - Maximum continuous 75°C minimum to40°C (w/o impact) Mechanical - Terminal Accommodation - #10 AWG - #6 AWG solid or stranded copper wire only |
| Connectivity | Screw Terminals |
| Package Quantity | 1 |
