Conduit Body, 23.2 cu. in Capacity, T Body
| Conduit Outlet Body Type | Conduit Outlet Body |
|---|---|
| Item | Conduit Outlet Body |
| Hazardous Location | Yes |
| Hub Size | 1-1/4 in |
| Series | Duraloy 8 |
| Conduit Outlet Body Material | Iron |
| Conduit Outlet Body Style | T |
| Material | Iron |
| Conduit Outlet Body Capacity | 23.2 cu in |
| Conduit Outlet Body Hub Size | 1-1/4 in |
| Includes | Set Screw Hubs |
| Conduit Outlet Body Hub Style | Threaded |
| For Use With | IMC, RMC |
| Special Features | Set Screw Hubs |
| Back Type | Flat |
| Color | Gray |
| Conduit Outlet Hub Size | 1-1/4 in |
| Standards | CSA, UL |
| Form | Form 8 |
| Body Style | T |
| Body Capacity | 23.2 cu in |
| Connection Type | Threaded |
| Overall Width | 4 in |
| Compatible Conduit Type | RMC, IMC |
| Connection Orientation | Multi-Angle |
| Hub Style | Threaded |
| Shape | T |
| Overall Height | 4 in |
| Body Type | Conduit Outlet Body |
| Finish | Powder Coated |
| Number of Hubs | 3 |
| Thread Gender | Female |
| Thread Type | NPT |
| Compatible Conduit Trade Size | 1-1/4 in |
| Trade Size | 1-1/4 in |
| Hazardous Location Rating | Class I Zone 2, Class I, Division 2 |
| Thread Size | 1 1/4 in |
| Overall Length | 9-1/4 in |
| Compatible Cover | 180F, 180S, 280F, 280S, 380F, 380S, 480F, 480S, 580F, 580S, 680F, 680S, 880F, 880S, 980F, 980S |
| Height | 4 in |
| Width | 4 in |
| Length | 9-1/4 in |
| Each - Width | 4 in |
| Dimensions | 9-1/4 in x 4 in x 4 in |
| Application | To provide access to conductors for pulling, splicing, and maintenance. Threaded for rigid conduit and IMC. |
| Finish Type | Powder Epoxy Paint |
| Hub Pattern | T |
| Type | Conduit Body |
| Package Quantity | 1 |
