Interruptor de desconexión cerrado no fusible, 600V AC, NEMA 12K, 4, 4X.
| Item | Enclosed Disconnect Switch |
|---|---|
| Protection Method | Nonfusible |
| Amps | 100 |
| Duty | Heavy Duty |
| Voltage | 600 V AC |
| Phase | 3 |
| HP | 50 hp @ 600V AC |
| NEMA Enclosure Type | 4, 12K, 4X |
| IP Rating | 66 |
| Material | Non-Metallic |
| Number of Wires | 5 |
| Number of Poles | 3 |
| Contact Form | 3PST |
| Depth | 5.9 in |
| Neutral Assembly Included | Yes |
| Includes | Auxiliary Contact 2EAV4 Preinstalled |
| Width | 6.9 in |
| Standards | UL/CSA |
| Fusible / Nonfusible | Nonfusible |
| Height | 10 in |
| Series | Non-Fused |
| Handle Color | Red |
| Type | Disconnect Switches |
| Enclosure Type | Enclosed |
| Switch Type | Three Pole Unfused |
| NEMA Enclosure Rating | 4X |
| Housing Material | Non-Metallic |
| Standard Conduit Size | 1-1/4 in |
| For Fuse Class | Not Applicable |
| For Environment | Indoor & Outdoor Rated |
| Current Rating | 100 A |
| Environment | Indoor, Outdoor |
| Horsepower @ 600V AC | 50 HP |
| Resistance Properties | Corrosion-Resistant, Impact-Resistant, UV-Resistant |
| Operating Temperatures | Max Continuous- 75 Degrees C, Minimum- -40 Without Impact |
| Listing and Certifications | UL Listed and CSA Certified |
| Amperage | 100 A |
| Current / Amperage Rating | 100 A |
| Mounting Method | External fully adjustable feet |
| Industry Standard(s) | UL Listed |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current & voltage Electrical - Dielectric Voltage - Withstands 3000V AC minimum Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability - UL94-5VA and V0 Classification Environmental - Operating Temperature - Max Continuous 75°C,Min Continuous -40°C w/o impact Environmental - UV Resistance - All materials are UV stabilized Mechanical - Impact Resistance - In accordance with UL 746C Mechanical - Mounting - Non-Metallic - External fully adjustable feet Mechanical - Product Identification - Identification and ratings are part of external label Mechanical - Terminal Identification - In accordance with UL, CSA and international conventions |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Length | 11 in |
| Application | Labelless |
| Amperage Rating | 100 A |
| Dimensions | 11 in x 7-3/4 in x 5.94 in |
| Dielectric Strength | Withstands 3000V AC minimum |
| Style | Heavy Duty |
| Package Quantity | 1 |
