Single Piece Molded Adapter, 5-15P, L5-30R
| Item | Plug-In Adapter |
|---|---|
| Number of Outlets | 1 |
| Voltage | 120V AC |
| Color | White |
| Power Indicator | No |
| Housing Material | Thermoplastic |
| NEMA Receptacle Configuration | L5-30R |
| NEMA Plug Configuration | 5-15P |
| Blade End Style | Straight Blade |
| Plug Configuration - Ext. Cords and Power Strips | No Swivel, Straight |
| Standards | CSA Certified |
| Connector Type | L5-30R |
| Plug Configuration | 5-15P |
| Outlet Surge Protection | No |
| Telephone/Fax Surge Protection | No |
| Slot End Rating | 30A 125V |
| Blade End Rating | 15A 125V |
| Circuit Breaker | No |
| Slot End Style | Locking |
| Surge Protection Indicator | No |
| NEMA Connector | L5-30R |
| USB Charging Port | No |
| Nema Rating | 5-15P To L5-30R |
| Number Of Wires | 3-Wire Grounding |
| Wattage | 3750 |
| Brand | Hubbell Wiring Device-Kellems |
| Connectivity | Plug-In |
| Phase | Single Phase |
| Carton Quantity | 10 |
| Number Of Poles | 2 |
| Display Size | Standard Sized Product |
| Application | Straight Blade Male to Locking Female |
| Performance | Environmental - Moisture Resistance - IP20 Suitability |
| Material | Thermoplastic |
| Mounting Hardware Material | Plug-In |
| Amperage | 15 A |
| Environmental Rating | Indoor Dry Unless Protected By Additional Means |
| Power Indicating Light | No |
| Blade End Current Rating | 15 A |
| Slot End Number of Wires | 3 |
| Blade End Number of Wires | 3 |
| For Location | Indoor |
| Surge Protection | No |
| Housing Color | White |
| Slot End Current Rating | 15 A |
| Blade End Connection Type | Straight Blade |
| Resistance Properties | Moisture Resistant |
| Slot End Connection Type | Locking |
| Number of USB Ports | 0 |
| Maximum Surge Current | Not Applicable |
| Slot End Voltage Rating | 125V AC |
| Adapter Type | Locking-Blade to Straight-Blade |
| Blade End Voltage Rating | 125V AC |
| Maximum Surge Energy | Not Applicable |
| Female End Rating | 30A 125V, 2p3w Twist-Lock |
| Adapter Style | One Piece |
| Poles and Wires | 2 Pole, 3 Wire Grounding |
| Male End Rating | 15A 125V, 2p3w Straight Blade |
| Moisture Resistance | IP20 |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Item Type | Adapter |
| Material - Mounting Hardware | Plug-In |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Amperage Rating | 15 A |
| Current / Amperage Rating | 15 A |
| Package Quantity | 1 |
