USB Receptacles SNAP8300UACR
| Item | Snapconnect receptacle |
|---|---|
| Includes | Mounting Screw, Mounting Strap |
| Number of Poles | 2 |
| Phase | Single |
| Number of Wires | 3 |
| Standards | cULus Listed to UL498, UL1310 |
| Wiring Method | Back |
| Resistance Properties | Tamper Resistant |
| Includes Mounting Hardware | Yes |
| Minimum Operating Temperature | -40 deg F |
| USB Charging Capacity | 3 A @ 9V |
| Mount Hole Center-to-Center Height | 3.81 in |
| Minimum Wire Size | 14 AWG |
| Mount Type | Flush |
| Market | Residential |
| UL 94 Flammability Rating | V-2 |
| Wire Connection Type | Modular Wiring |
| Power Indicating Light | Yes |
| GFCI | No |
| Maximum Wire Size | 10 AWG |
| Number of USB Ports | 2 |
| USB Standard | 1.2 |
| Current Rating | 20 A |
| Housing Material | Thermoplastic |
| USB Connection Type | A, C |
| Grade | Hospital Grade |
| Number of Outlets | 2 |
| Maximum Operating Temperature | 167 deg F |
| Electrical Connection Type | Straight Blade |
| NEMA Receptacle Configuration | 5-20R |
| Overall Depth | 1-1/2 in |
| Grounding | Grounded |
| Receptacle Type | Duplex |
| Contact Material | Copper |
| Housing Color | Red |
| Voltage Rating | 125 V |
| Package Quantity | 1 |
