El receptáculo GFCI de Hubbell Wiring Device-Kellems cuenta con una capacidad de 15 amperes y 125VAC, con diseño de 5-15R en color gris. Cumple con los estándares de seguridad y es ideal para uso residencial o comercial.
| Item | DIN Rail GFCI Receptacle |
|---|---|
| Connection Orientation | Straight |
| Cover Type | No Cover |
| Current Rating | 15 A |
| GFCI | Yes |
| Phase | Single |
| Grounding | Grounded |
| Housing Color | Gray |
| Housing Material | Nylon |
| Mounting Type | Panel |
| NEMA Enclosure Rating | 1 |
| NEMA Receptacle Configuration | 5-15R |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Polarized | Yes |
| Standards | UL Listed |
| Outlet Type | Decorator |
| Wiring Method | Side |
| Voltage | 125VAC |
| NEMA Configuration | 5-15 |
| Tamper Resistant | No |
| Color | Gray |
| Voltage - Plugs and Receptacles | 125 V |
| Outlet Type - Plugs and Receptacles | Decorator Duplex |
| NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| Wiring Method - Plugs and Receptacles | Side |
| Power Indicator | Yes |
| Color - Plugs and Receptacles | Gray |
| Surge Suppression | No |
| HP | 0.5 hp |
| Weather Resistant - Plugs and Receptacles | No |
| Application Environment | Industrial |
| Amps | 15 |
| Weather Resistant | No |
| Reset Type | Automatic |
| Item - Plugs and Receptacles | DIN Rail Receptacle |
| Amps - Plugs and Receptacles | 15 |
| Amps - Plugs and Receptacles | 15 A |
| Self-Testing | No |
| Mounting Type - Plugs and Receptacles | Panel |
| Shrouded | No |
| Horsepower Rating | 0.5 HP |
| Flange Shape | Square |
| AFCI | No |
| Voltage Rating | 125 V AC |
| Market | Industrial |
| Grade | General Use |
| Hub Type | Feed Through |
| Number of Gangs | 1 |
| Self Testing | No |
| Receptacle Type | Duplex |
| Mount Type | Surface |
| Overall Depth | 2.4 in |
| Surge Protection | No |
| Features | DIN Rail Mounted |
| Includes Mounting Hardware | Yes |
| Includes | Mounting Hardware |
| Flange Type | Non-Flanged |
| Type | Box, Device |
| Device Color | Gray |
| Product Type | Drub |
| Device Rating | 125V, 15A |
| DIN Rail Utility Box Variety | Complete Unit w/GFCI |
| DRUB Mounting | Vertical |
| Certifications | UL Listed, CSA Certified |
| Nema Rating | 5-15R |
| Knockouts | None |
| Voltage Rating Description | 125 V |
| Application | Unit Pre-Wired with GFCI Duplex |
| Construction | Molded and Fabricated |
| Material - Mounting Hardware | DIN Rail Mount, Vertical Mount |
| Item Type | Complete Unit |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Cable Entry | Terminals |
| Current / Amperage Rating | 15 A |
| Industry Standard(s) | UL Listed |
| Display Size | Standard Sized Product |
| Package Quantity | 1 |
