Descubre los receptáculos GFCI estándar comercial de Hubbell Wiring Device-Kellems, diseñados para prevenir fallas a tierra en entornos comerciales. El modelo GFRST15U ofrece protección confiable y durabilidad para tu negocio.
| Item | GFCI Receptacle |
|---|---|
| Connection Orientation | Straight |
| Cover Type | No Cover |
| Current Rating | 20 A |
| GFCI | Yes |
| Phase | Single |
| Grounding | Grounded |
| Housing Color | Red |
| Housing Material | Nylon |
| NEMA Enclosure Rating | 1 |
| NEMA Receptacle Configuration | 5-20R |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Polarized | Yes |
| Standards | NEC |
| Voltage - Plugs and Receptacles | 125 V |
| Application Environment | Heavy Use Hospital Grade |
| Surge Suppression | No |
| Self-Testing | Yes |
| Type | Standard |
| NEMA Configuration | 5-20 |
| Special Features | Ground Fault Indicator |
| Reset Type | Manual |
| Power Indicator | Yes |
| Color | Brown |
| Weather Resistant - Plugs and Receptacles | Yes |
| HP | 1 hp |
| NEMA Receptacle Configuration - Plugs and Receptacles | 5-20R |
| Tamper Resistant | No |
| Amps - Plugs and Receptacles | 20 A |
| Color - Plugs and Receptacles | Red |
| Outlet Type - Plugs and Receptacles | Decorator Duplex |
| Wiring Method - Plugs and Receptacles | Modular |
| Wiring Method | Back |
| Resistance Properties | Tamper Resistant, Weather Resistant |
| Face Plate Height | 2.8 in |
| Face Plate Width | 1.8 in |
| Receptacle Type | Decorator Duplex |
| Self Testing | Yes |
| Number of Gangs | 1 |
| Mount Hole Center-to-Center Height | 3.3 in |
| Voltage Rating | 125 V AC |
| Wire Connection Type | Modular Wiring |
| Features | Tamper and Weather Resistant SnapConnect |
| Overall Depth | 1-1/2 in |
| Number of Poles & Wires | 2 Pole / 3 Wire |
| Key Resistance Properties | Tamper Resistant - Weather Resistant - HUBBELL, Weather Resistant - Tamper Resistant - HUBBELL, Weather Resistant - Weather Resistant - HUBBELL |
| Additional Electrical Protection | GFCI |
| AFCI | No |
| Hub Type | Feed Through |
| Wire Connection Types | Snap-In Module |
| Flange Type | Non-Flanged |
| Grade | Hospital Grade |
| Includes | Mounting Hardware, Wall Plate |
| Shrouded | No |
| Horsepower Rating | 1 HP |
| Includes Mounting Hardware | Yes |
| Contact Material | Brass |
| Market | Commercial |
| Surge Protection | No |
| Mount Type | Flush |
| Additional Electrical Protections | GFCI |
| Maximum Wire Size | 12 AWG |
| Voltage Rating Description | 125 V |
| Current / Amperage Rating | 15 A |
| Series | Heavy Duty |
| Industry Standard(s) | Meets All NEC® Requirements |
| Style | Assembled In USA |
| Nema Rating | 5-15R |
| Package Quantity | 1 |
