Este receptáculo con bloqueo de 20 A y 250V AC, 2 polos, es ideal para aplicaciones industriales y comerciales que requieren una conexión segura y confiable.
| Item | Locking Receptacle |
|---|---|
| Current Rating | 20 A |
| Voltage Rating | 250V AC |
| Number of Poles | 2 |
| Housing Color | Black |
| Cover Type | No Cover |
| IP Rating | IP20 |
| Standards | Certified for current interrupting at full rated current |
| Wiring Style | Standard |
| Special Features | Molded In or Stamped On |
| Material | Steel-zinc-plated |
| Spring Material | .040" Brass |
| Base Material | Nylon Polyester |
| Operating Temp. | Maximum Continuous 75A Deg C; Minimum -40A Deg C (w/o impact) |
| Flammability | UL 94 VO for Receptacles and Inlets. HB or better for Plugs and Connectors. |
| Terminal Designations | Terminals identified in accordance with UL 498 (X, Y, Z, White, Green) |
| Temp. Rise | Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75. |
| Lock Type | Replacement-use |
| Wire Size | #10 AWG |
| Package Quantity | 1 |
