Locking Receptacle, L14-20R, 20 A, 125/250V AC, Single Phase, 3 Pole, Screw Terminals
| Item | Locking Receptacle |
|---|---|
| NEMA Receptacle Configuration | L14-20R |
| Current Rating | 20 A |
| Voltage Rating | 125/250V AC |
| Phase | Single |
| Number of Poles | 3 |
| Number of Wires | 4 |
| Wire Connection Type | Screw Terminals |
| Shrouded | Yes |
| Housing Color | Gray |
| Cover Type | No Cover |
| IP Rating | IP20 |
| Standards | Certified to CSA C22.2 No.42 Fed.Spec. W-C-596 Listed to UL 498 |
| Material | zinc plated Steel |
| Wiring Style | Shrouded |
| Flange Material | Gray Valox 357U |
| Special Features | Molded In or Stamped On |
| Application | Heavy Duty Industrial Shrouded |
| Operating Temp. | Maximum Continuous 75A Deg C; Minimum -40A Deg C (w/o impact) |
| Spring Material | .031" Brass |
| Lock Type | Twist-lock |
| Flammability | HB or better per UL94 or CSA 2.2 No. 0.6 |
| Temp. Rise | Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75. |
| Terminal Designations | Terminals identified in accordance with UL 498 |
| Wire Size | #14 to #8 AWG Copper Only |
| Display Size | Standard Sized Product |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - V2 or better per UL94/CSA 22.2 No.0.17 Environmental - Moisture Resistance - IP20 Suitability Environmental - Operating Temperatures - Maximum Continuous 75°C, Minimum -40°C (w/o impact) Mechanical - Terminal Accommodation - #16 AWG - #8 AWG solid or stranded copper wire only. Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Dimensions | 4.77 in x 2.85 in x 3.14 in |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Amperage Rating | 20 A |
| Material - Mounting Hardware | Screw Mounting |
| Height | 3.14 in |
| Industry Standard(s) | Certified to CSA C22.2 No.42 Fed.Spec. W-C-596 Listed to UL 498 |
| Width | 2.85 in |
| Length | 4.77 in |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Horsepower - Maximum | 2 |
| Number of Gang(s) | 1-Gang |
| Dielectric Strength | Withstands 2,000V minimum |
| Package Quantity | 1 |
