Este enchufe de clavija y pasador es ideal para aplicaciones de 100 A y 250V CA en entornos monofásicos. Con 3 polos y toma de tierra IEC, cumple con los estándares de seguridad NEMA 4X.
| Item | Pin & Sleeve Plug |
|---|---|
| Current Rating | 100 A |
| Voltage Rating | 250V AC |
| Phase | Single |
| Number of Poles | 3 |
| Number of Wires | 4 |
| IP Rating | IP67 |
| NEMA Enclosure Rating | 4X |
| Wire Connection Type | Terminals |
| Connection Orientation | Straight |
| Switch Rated | No |
| Grounding Style | IEC |
| Housing Color | Yellow |
| Cap Type | No Cap or Cover |
| For Maximum Cable Diameter | 1.78 in |
| For Minimum Cable Diameter | 1.2 in |
| Standards | CSA Certified LR280C, IEC 60309-1, IEC 60309-2, UL E146033 |
| Resistance Properties | Impact Resistant, Moisture Resistant, Watertight |
| Voltage | 250VAC |
| Body Material - Pin and Sleeve | Nylon |
| Color | Yellow |
| Body Material | Nylon |
| Color - Plugs and Receptacles | Yellow |
| Amps - Plugs and Receptacles | 100 |
| Features | Gasketed Sealing Ring Provides Watertight Seal, Raised Collar Surrounds Each Phase Pin |
| Amps | 100 |
| Item - Plugs and Receptacles | Watertight Pin and Sleeve Plug |
| Voltage - Plugs and Receptacles | 250V AC |
| Phase - Electrical | 1 |
| Shrouded | Yes |
| Grounding | Grounded |
| Maximum Wire Size | 1/0 AWG |
| Overall Length | 12.63 in |
| Minimum Operating Temperature | -40 deg C |
| Reverse Service | No |
| UL 94 Flammability Rating | HB |
| Housing Material | Non-Metallic |
| Power Indicating Light | No |
| Minimum Wire Size | 3 AWG |
| Maximum Operating Temperature | 75 deg C |
| Package Quantity | 1 |
