Este clavija y conector de perno y manga de 20 A y 600V AC es ideal para aplicaciones industriales en entornos exigentes. Cumple con los estándares NEMA 4X y garantiza un rendimiento confiable y seguro.
| Item | Pin & Sleeve Plug |
|---|---|
| Current Rating | 20 A |
| Voltage Rating | 600V AC |
| Number of Wires | 6 |
| NEMA Enclosure Rating | 4X |
| Standards | CSA Certified, UL Listed |
| Receptacle | Male/Female/Female |
| Enclosure Type | NEMA 4X |
| Jacket Color | Gray |
| Max. Voltage | 600V AC |
| For Use With | 2DZU4, 2DZU5, 2DZU6, 2DZU7, 2DZU8, 2DZV4 Female Receptacle, 2DZV8 Male Receptacle |
| Gauge/Conductor | 12/10 |
| Type | Tap |
| Plug Type | 6-Wire and 4-Wire |
| Conductor Material | Copper |
| Amps AC | 20 A |
| Plug End | Male/Female/Female |
| Color | Gray |
| Component Type | Tee |
| Grounding | Isolated Ground |
| Contact Material | Copper |
| Gender Configuration | Male x Female x Female |
| Package Quantity | 1 |
