Straight Blade Devices, IEC 320 Devices, Female Connector, 16A 250V, International Rated, Pressure Screw Terminal, Black, Single Pack
| Voltage | 250 V |
|---|---|
| NEMA Receptacle Configuration | Non-NEMA |
| Height | 1.36 in |
| Width | 1.42 in |
| Length | 2.74 in |
| Standards | UL Listed File No. E1706; CSA certified File No. 17337; UL classified to IEC 320 File No. E111246; TUV and VDE certified at File No. 12469 1550 1002.; UL 94 HB or better Flammability; IEC 320 |
| Material | Nylon |
| Color | Black |
| Amps | 1.25 |
| Cord Size | 0.275 to 0.475 in |
| Special Features | IP20 Moisture Resistance |
| Item | Valise |
| Amperage | 1.25 A |
| Cord Dia. Range | 0.325-0 .475 (8.0-12.0) |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Number Of Poles | 2-Pole |
| Voltage Rating | 250 V |
| Number Of Conductors | 3-Wire Grounding |
| Wattage | 7,500 W |
| Nema Rating | Non-NEMA |
| Number Of Wires | 3-Wire |
| Dimensions | 2.74 in x 1.42 in x 1.36 in |
| Connectivity | Screw Terminals |
| Environmental Rating | Indoor Dry Unless Protected By Additional Means |
| Dielectric Strength | Withstands 2,000V minimum |
| Current Rating | 1.25 A |
| Insulation | Insulated Body |
| Carton Quantity | 10 |
| Brand | Hubbell Wiring Device-Kellems |
| Wire Size | North American-#16AWG-#12AWG; International-1.55mm²-2.5mm². |
| Temp. Rating | Max Continuous- 75 Degrees C, Minimum- -40 Without Impact |
| Display Size | Standard Sized Product |
| Mounting Hardware Material | Cord Mounted |
| Weight | 0.2 lb |
| Maximum Operating Temperature | 75 deg C |
| Minimum Operating Temperature | -40°C |
| Minimum Wire Size | 16 AWG |
| Maximum Wire Size | 12 AWG |
| Contact Material | Brass |
| Voltage Rating Description | 250 V |
| Current / Amperage Rating | 1.25 A |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Material - Mounting Hardware | Cord Mounted |
| Temperature Rating | Max Continuous- 75 Degrees C, Minimum- -40 Without Impact |
| Industry Standard(s) | CSA certified 20A 250V AC-File No. 17337 UL classified to IEC 320, 16A 250V AC-File No. E111246 UL Listed 20A 250V AC-File No. E1706 |
| Amperage Rating | 1.25 A |
| Item Type | Valise |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Performance | Electrical - Dielectric Voltage - Withstands 2,000V minimum Electrical - Rating - 16A 250V AC for European service 20A 250V AC for North American service Environmental - Flammability - UL 94 HB or better Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Cord Accommodation - .325" - .475" (8.0-12.0) Mechanical - Terminal Accommodation - North American to #16-12 AWG stranded or solid copper conductor only,International to 1.55mm²-2.5mm²,Terminal Identification Terminals identified in accordance with UL 498 and CSA |
| Conductor Range | #14 AWG to #12 AWG |
| Cord Range | 0.325"-0 .475" |
| Package Quantity | 1 |
