Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Gray, Single Pack
| Height | 1.19 in |
|---|---|
| Width | 1.63 in |
| Color | Gray |
| Phase | Single Phase |
| Application | Heavy Duty Industrial |
| Length | 3.28 in |
| Flammability | Top: UL 94V-2, Base: UL 94V-0 |
| Auto Self-grounding Clip | Stainless steel |
| Operating Temperatures | Maximum continuous 75°C, minimum -40°C |
| Device Color | Gray |
| Base | PBT |
| Current Interrupting | Certified for current interrupting at full rated current |
| Mounting Strap | Brass |
| Ground Contact | Brass |
| Mounting Screws | Zinc plated steel |
| Face | Nylon |
| Dielectric Voltage | Withstands 2,000V minimum |
| Power Contacts | .037 in. Brass |
| Terminal Identification | Terminals identified in accordance with UL 498 and CSA |
| Terminal Accommodation | #12-#10 AWG copper stranded or solid conductor only |
| Type | Single Receptacle |
| Series | Extra Heavy Duty |
| Style | Finder Groove Face |
| Number Of Wires | 3-Wire |
| Wire Size | #12 AWG to #10 AWG |
| Display Size | Standard Sized Product |
| Item Type | Single |
| Number Of Poles | 2-Pole |
| Current Rating | 20 A |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Industry Standard(s) | Certified to CSA 22.2, No. 42 File 285 Guide RTRT Fed Spec WC596G NEMA® WD-6 Compliant UL Listed to UL498 File No. E2186 |
| Wattage | 5000 W |
| Nema Rating | 6-20R |
| Dimensions | 3.28 in x 1.63 in x 1.19 in |
| Voltage Rating Description | 250 V |
| Horsepower - Maximum | 2 |
| Amperage Rating | 20 A |
| Connectivity | Back and Side Wired Screw Terminals |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - Top: UL 94V-2, Base: UL 94V-0 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12-#10 AWG copper stranded or solid conductor only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Dielectric Strength | Withstands 2,000V minimum |
| Current / Amperage Rating | 20 A |
| Material - Mounting Hardware | Screw Mounting |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Package Quantity | 1 |
