TradeSelect, Dispositivos de hoja recta, Grado residencial, Tomacorrientes, Dúplex resistente a la intemperie y al vandalismo, 15A 125V, 5-15R.
| Color | Brown |
|---|---|
| Material | Thermoplastic |
| Phase | Single Phase |
| Application | Residential Receptacles |
| Wire Size | #14 AWG to #12 AWG |
| Nema Rating | 5-15R |
| Display Size | Standard Sized Product |
| Amperage Rating | 15 A |
| Number Of Wires | 3-Wire Grounding |
| Current / Amperage Rating | 15 A |
| Voltage Rating | 125 VAC |
| Item Type | Traditional Duplex |
| Voltage Rating Description | 125 VAC |
| Current Rating | 15 A |
| Number Of Poles | 2-Pole |
| Material - Mounting Hardware | Screw Mounting |
| Environmental Conditions | Weather Resistant |
| Wattage | 1875 |
| Connectivity | Push and Side Wire |
| Performance | Environmental - Operating temperature - -20°C to 60°C Mechanical - Terminal - Terminal screws accepts up to #12 AWG, Push wire designed for #14 AWG solid copper wire only |
| Package Quantity | 1 |
