El receptáculo duplex hermético Hubbell Wiring Device-Kellems ofrece una solución resistente al agua para entornos exigentes. Con capacidad de 20 A y 125V AC, este receptáculo de 2 polos es ideal para montaje al ras.
| Item | Watertight Duplex Receptacle |
|---|---|
| NEMA Receptacle Configuration | L5-20R |
| Current Rating | 20 A |
| Voltage Rating | 125V AC |
| Phase | Single |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Wire Connection Type | Screw Terminals |
| Shrouded | Yes |
| Housing Color | Gray |
| Mount Type | Flush |
| Cover Type | No Cover |
| IP Rating | IP66 |
| NEMA Enclosure Rating | 4X |
| Standards | cULus Listed, UL Listed |
| Resistance Properties | Impact Resistant, Watertight |
| Flange Type | Flanged |
| Grade | Industrial |
| Shrouded / Non-Shrouded | Shrouded |
| Mounting Type | Flush Mount |
| Special Features | Conduit Feed |
| Material | Nylon |
| Wiring Style | Standard |
| Number of Gangs | 2 |
| Connection Orientation | Straight |
| Polarized | Yes |
| AFCI | No |
| Flange Shape | Rectangular |
| Market | Industrial |
| Housing Material | Nylon |
| Color | Gray |
| Amps | 20 |
| Voltage | 125V AC |
| NEMA Rating | 4x |
| NEMA Configuration | L5-20 |
| Package Quantity | 1 |
