Conector estanco de clavija y toma, 16 A, 100/130V AC, 2 polos, NEMA no clasificado. Ideal para entornos húmedos o expuestos a salpicaduras de agua. Resistente y duradero para aplicaciones industriales.
| Item | Watertight Pin & Sleeve Connector |
|---|---|
| Current Rating | 16 A |
| Voltage Rating | 100/130V AC |
| Number of Poles | 2 |
| Number of Wires | 3 |
| NEMA Enclosure Rating | Not Rated |
| Housing Color | Yellow |
| Standards | UL Listed File E146032, E146033, UL Standard UL1682 & UL1686C2, CSA Certified File LR280C, LR285C, CSA Standard C22.2 No. 182.1, UL Classified to IEC60309-1 |
| Application | High Ampacity Connections |
| Conductor Range | #14 AWG to #10 AWG |
| Insulation | Insulated Body |
| Connectivity | Pressure Terminal Screws |
| Style | Standard Service |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Series | HBL Heavy Duty |
| Number Of Conductors | 3-Wire Grounding |
| Current / Amperage Rating | 16 A |
| Display Size | Standard |
| Material - Mounting Hardware | Cord Mounted |
| Environmental Conditions | Watertight |
| Temperature Rating | Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact. |
| Industry Standard(s) | CSA Certified File LR280C UL Classified to IEC 60309-1 IEC 60309-2 UL Listed, File E146033 |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - 3000V AC Electrical - Max. Working Voltage - 600V RMS Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No. 0.17 Environmental - Ingress Protection - IP67 Suitability Environmental - Moisture Resistance - Watertight per IEC 60309-1 Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum - 40°C w/o impact Mechanical - Impact Resistance - Per CSA C22.2 No.182.1 /UL1682 Mechanical - Product Identification - Identification and ratings are a permanent part of the device housing Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions |
| Package Quantity | 1 |
