Shrink End Cap, 1.38in ID, Bk, 3-5/16in, PK5
| Item | Dual Wall End Cap |
|---|---|
| Shrink Ratio | 3:1 |
| Shrink Tubing Wall Type | Medium Wall |
| Shrink Tubing I.D. Before Shrinking | 1.38 in |
| Material | Cross-Linked Polyolefin with Adhesive |
| Color | Black |
| Length | 3.31 in |
| Temp. Range | -55 to 110 deg F |
| Min. Shrink Temp. | 248 deg F |
| Use Shrink Tubing With Wire Size | 500 to 1500 kcmil |
| Features | Recommended for Open Air and Underground Power Distribution Cables With PVC, Lead, or XLPE Sheaths |
| I.D. After Shrinking | 0.59 in |
| Shrink Tubing Material | Cross-Linked Polyolefin |
| Shrink Tubing Adhesive Lined | Yes |
| Shrink Tubing Wall Thickness After Shrinking | 0.118 in |
| Shrink Tubing Usable Temp. Range | -55 to 110 deg F |
| Max. Voltage | 1,000 V |
| Shrink Tubing Type | Heat Shrink End Cap |
| Shrink Tubing Length | 3-5/16 in |
| Flame Retardant | No |
| Standards | RoHS |
| I.D. Before Shrinking | 1.38 in |
| Use With Wire Size | 4/0 AWG to 400 MCM |
| Tubing Wall Type | Medium Wall |
| Adhesive Lined | Yes |
| Dielectric Strength | 1,000 V |
| Application | General |
| Shrink Tubing Properties | UV Light Resistant |
| Wall Thickness After Shrinking | 0.118 in |
| Max. Temp. Rating | 110 deg F |
| Min. Temp. Rating | -55 deg F |
| Length (Straight Wireway) | 3.31 in |
| Heat Shrink Type | Medium Wall |
| Package Quantity | 5 |
