DC Power Supply, 100/240V AC, 24/28V DC, 300W, 12.5A, Wall
| Item | DC Power Supply |
|---|---|
| Input Voltage | 100/240V AC |
| Output Voltage | 24/28V DC |
| Power Rating | 300 W |
| Output Amps | 12.5 A |
| Mounting | Wall |
| Case Material | Aluminum Alloy Case |
| Phase - Electrical | Single |
| Style | Switching |
| Height | 183 mm |
| Width | 182 mm |
| Depth | 59 mm |
| Hz | 50/60 Hz |
| Hold Up Time | 33/33 msec @ 100/230 V AC |
| Protection | IP 65; IP 67 |
| IP Rating | IP65/67 |
| Operating Temp. Range | -20 to 55 deg C |
| Standards | EN 55011, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2 AD, EN 61000-4-2 CD, EN 61000-4-3, EN 61000-4-4 Burst, EN 61000-4-5 Surge, EN 61000-4-6, EN 61000-4-8, IEC 600068-2-6, IEC 60068-2-27, VDE 0160 |
| Features | Additional Diagnostics by Measuring Current, Voltage and Mains Quality as Well as Counting Operating Hours, Installation Without Control Cabinet, Protection of the Wiring Via Configurable Electronic Circuit Breakers |
| Status Indicator | Green LED |
| Ambient temperature [°C] | -25...55 |
| Protection class | I |
| Unterstützte IO-Link Revision | 1.1 |
| Input current (nominal voltage 230 V AC / 50 Hz) [A] | 1.68 |
| IO-Link revision | 1.1 |
| Min. process cycle time [ms] | 2.2 |
| Vibration resistance | IEC 600068-2-6 2...17.8 Hz± 1.6mm / 17.8...500 Hz 2 g |
| SIO mode | yes |
| Mains buffering time (nominal voltage 230 V AC / 50 Hz) [ms] | 44 |
| Communication interface | IO-Link |
| Number of output circuits | 4 |
| Electrical connection | Connector: 1 x M12; coding: A; Locking: brass, Connector: 2 x M12; coding: A; Locking: brass, Connector: 1 x 7/8"; Locking: brass |
| EMC | EN 61000-4-2 CD 8 kV / failure criterion A EN 61000-4-2 AD 15 kV / failure criterion A EN 61000-4-3 80 Mhz...2.7 GHz / 20 V/m failure criterion A EN 61000-4-3 2.7 GHz...6 GHz kV / 10 V/m failure criterion A EN 61000-4-8 50 / 60 Hz / 30 A/m failure criterion A EN 61000-4-4 Burst 4 kV / failure criterion A EN 61000-4-5 Surge 2 kV Lx / Ly / failure criterion A EN 61000-4-5 Surge 4 kV L / PE / failure criterion A EN 61000-4-5 Surge 1 kV + / - / failure criterion A EN 61000-4-5 Surge 1 kV + - / PE / failure criterion A EN 61000-4-5 Surge 1 kV + - / PE / failure criterion A EN 61000-4-5 Surge 1 kV DC-OK / PE / failure criterion A EN 61000-4-6 0.15...80 MHz / 20 V failure criterion A EN 61000-4-11 0 V up to 1 cycle / failure criterion A EN 61000-4-11 40 % of V / 200 ms failure criterion A EN 61000-4-11 70 % of V / 500 ms failure criterion A EN 61000-4-11 0 V / 5000 ms failure criterion C VDE 0160 1550 V / 1.3 ms failure criterion A EN 55032 Class B EN 55032 Class B EN 55011 Class B EN 61000-3-2 EN 61000-3-3 |
| Efficiency (nominal voltage 120 V AC / 60 Hz) [%] | 94.3 |
| Input current (nominal voltage 120 V AC / 60 Hz) [A] | 3.2 |
| Max. height above sea level [m] | 5000 |
| Max. relative air humidity [%] | 95; (relative humidity) |
| Max. output current at max. output voltage [A] | 10.7 |
| Power factor (nominal voltage 230 V AC / 50 Hz) | 0.97 |
| Max. output current at min. output voltage [A] | 12.5 |
| Efficiency (nominal voltage 230 V AC / 50 Hz) [%] | 95.7 |
| Transmission type | COM3 (230,4 kBaud) |
| Max. power-on delay time [ms] | 1.3 |
| Mains buffering time (nominal voltage 120 V AC / 60 Hz) [ms] | 44 |
| Storage temperature [°C] | -40...85 |
| Pollution degree | 3 |
| Continuous shock resistance | IEC 60068-2-27 30 g 6 ms / 20 g 11 ms |
| Ambient temperature [°C] | -25...55 |
| Storage temperature [°C] | -40...85 |
| Maximum Efficiency @ 230V AC | 95.7% |
| Current - Output | 12 A |
| Input Frequency - Nominal | 50/60 Hz |
| Output Power - Peak | 600 W |
| Housing Material | Aluminum |
| Output Power - Rated | 300 W |
| Operating Temperature - Minimum | -13 deg F |
| Operating Temperature - Maximum | 131 deg F |
| Package Quantity | 1 |
