Maestro IO-Link, 16 entradas, 20 a 30VDC.
| Item | IO-Link Master |
|---|---|
| Standards | CE, cULus Listed, DIN EN 60068-2-27, DIN EN 60068-2-6 2008-10, DIN EN 60068-2-64 2009-04, EAC, EN 61000-6-2, EN 61000-6-4, UKCA |
| Application | I/O Modules for Field Applications |
| Electrical Connection Type | M12 Connector |
| Transmission Type | COM1 (4.8 kBaud), COM2 (38.4 kBaud), COM3 (230.4 kBaud) |
| Operating Voltage | 20 to 30V DC |
| Minimum Ambient Temperature | -25 Degrees C |
| Number of Digital Outputs | 8 |
| Number of Digital Inputs | 16 |
| Maximum Ambient Temperature | 60 Degrees C |
| Housing Material | Polyamide |
| Current Consumption | 3,900 mA |
| Communication Interface | Ethernet, IO-Link |
| Protection Features | IP65, IP66, IP67, Protection Class III |
| Maximum Current Load Per Output | 300 mA |
| Transmission Rate | 100 MBps |
| IO-Link Revision | 1.1 |
| Max. current load total [A] | 3.6 |
| Protocol | PROFINET |
| Number of ports class A | 8 |
| Materials | housing: PA orange; socket: brass nickel-plated |
| Operating voltage [V] | 20...30 DC; (US; to SELV/PELV) |
| Max. relative air humidity [%] | 90 |
| Shock resistance | DIN EN 60068-2-27 |
| Total number of inputs and outputs | 16; (configurable) |
| Ambient temperature [°C] | -25...60 |
| Sealing material | FKM |
| Note on interfaces | CC-C (Conformance Class C) (IRT-Switch) Netload Class III SNMP (Simple Network Management Protocol) MRP (Media Redundancy Protocol) Supported network topologies: line ring |
| Daisy-chain function | fieldbus interface |
| Protection rating (NEMA 250) | 6P |
| X31 | Connector: M12; coding: A |
| IO-Link Port Class A X01...X08 | Connector: M12, coding: A, Sealing: FKM |
| Protection | IP 65; IP 66; IP 67 |
| Current consumption [mA] | 300...3900; (US) |
| EMC | EN 61000-6-2 EN 61000-6-4 |
| Number of inputs and outputs | Number of digital inputs: 16; Number of digital outputs: 8 |
| MTTF [years] | 78 |
| Chemical media | ISO 16750-5 AA, BA, BD, HLP, CC, DB, DC, DD, CA NEMA 250 5.13.1 AA |
| Vibration resistance | DIN EN 60068-2-64 2009-04 DIN EN 60068-2-6 2008-10 |
| Short-circuit proof | yes |
| Protection class | III |
| Max. current load per output [mA] | 300 |
| Switching level low [V] | 0...5 |
| Pollution degree | 2 |
| Transmission standard | 100Base-TX |
| Storage temperature [°C] | -25...85 |
| Factory settings | IP address: 0.0.0.0 subnet mask: 0.0.0.0 gateway IP address: 0.0.0.0 MAC address: see type label |
| IN / OUT X21, X22 | Connector: M12, coding: D, Sealing: FKM |
| Digital inputs protected against short circuits | yes |
| Switching level high [V] | 11...30 |
| Package Quantity | 1 |
