2.48 Inch Inside Width x 1.26 Inch Inside Height, 3.08 Inch Outside Width x 1.54 Inch Outside Height, 2.95 Inch Bend Radius
| Access Type | Snap Open |
|---|---|
| Overall Length (Feet) | 3 ft |
| Inside Height (Decimal Inch) | 1.2600 |
| Inside Height (mm) | 1.2600 in; 32 mm |
| Inside Width | 63 mm; 2.4800 in |
| Inside Width (Decimal Inch) | 2.4800 |
| Outside Height | 39.0 mm; 1.5400 in |
| Outside Width | 78.30 mm; 3.0800 in |
| Bend Radius | 75 mm; 2.9500 in |
| Outside Height (Decimal Inch) | 1.5400 |
| Link To Link Pitch | 1.2000 in |
| Outside Width (mm) | 78.30 |
| Bend Radius (mm) | 75 |
| Number of Sections | 27 |
| Link to Link Pitch (Decimal Inch) | 1.2000 |
| Standards Met | VDE 0304 IIC UL 94 V2; VDE 0304 IIC UL 94 HB |
| UNSPSC Code | 26121630 |
| Country of Origin | Germany |
| MSC Number | MSC# 05853957 |
