0.395" Max Depth of Cut, Uses TD 2, TS 2 Inserts
| Toolholder Type | External Grooving |
|---|---|
| Insert Seat Size | 2 |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.3950 |
| Minimum Groove Width (Decimal Inch) | 0.0790 |
| Toolholder Style | TTER |
| Maximum Groove Width (Decimal Inch) | 0.0690 |
| Insert Holding Method | Clamp |
| Compatible Insert Size Code | TD 2; TS 2 |
| Shank Height (Decimal Inch) | 0.3750 |
| Series | TTER/L-SH |
| Shank Length (Decimal Inch) | 4.2500 |
| Shank Length (Inch) | 4-1/4 |
| Overall Length (Inch) | 5 |
| Overall Length (Decimal Inch) | 5 |
| Multi-use Tool | Yes |
| Maximum Workpiece Diameter (Decimal Inch) | 0.7900 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.3750 |
| Head Length (Decimal Inch) | 0.75 |
| Head Length (Inch) | 3/4 |
| Primary Workpiece Material | Universal |
| UNSPSC Code | 23153308 |
| Toolholder Material | Steel |
| Coolant Through | No |
| MSC Number | MSC# 11129178 |
