0.472" Max Depth of Cut, Through Coolant, Uses TDX 3, SC*T 3, TSL 3 Inserts
| Toolholder Type | Face Grooving |
|---|---|
| Insert Seat Size | 3 |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.4720 |
| Minimum Groove Width (Decimal Inch) | 0.1180 |
| Toolholder Style | TTFIR |
| Maximum Groove Width (Decimal Inch) | 0.0870 |
| Insert Holding Method | Clamp |
| Compatible Insert Size Code | TDX 3; TSL 3; SC*T 3 |
| Series | TTFIR/L |
| Shank Length (Decimal Inch) | 6.7800 |
| Overall Length (Inch) | 8 |
| Overall Length (Decimal Inch) | 8 |
| Multi-use Tool | Yes |
| Maximum Workpiece Diameter (Decimal Inch) | 1.3000 |
| Minimum Overhang (Decimal Inch) | 0.787 |
| Maximum Overhang (Inch) | 1.3000 |
| Center to Cutting Edge (Decimal Inch) | 0.5160 |
| Minimum Hole Diameter (Decimal Inch) | 0.7870 |
| Head Length (Decimal Inch) | 1.22 |
| Primary Workpiece Material | Universal |
| UNSPSC Code | 23153308 |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| MSC Number | MSC# 13577598 |
