Block Level, 1-21/32" W, 12" L, Cast Steel
| Accuracy | 0.001 Degrees |
|---|---|
| Color | Black |
| Features | V-Groove on Bottom for Shafts (Shafts Diameter.76 to 4.56 in) |
| Includes | Case |
| Application | For Checking Accuracy of Horizontal and Vertical Surfaces on Posts |
| Top Read | Top Read Window |
| Number of 45 Degree Vials | 0 |
| Number of Level Vials | 1 |
| Number of Plumb Vials | 0 |
| Height (In.) | 1.65 |
| Total Number of Vials | 1 |
| Width (In.) | 1.66 |
| Number of Mounting Holes | 0 |
| Thickness (In.) | 1.654 |
| Characteristics | V-Groove on Bottom |
| Item | Block Level |
| Length (In.) | 12 |
| Construction | Cast Steel |
| Vial Material | Glass |
| Type | Electronic Digital |
| Frame Material | Cast Steel |
| Number of V-Grooves | 1 |
| Overall Length | 12 in |
| Overall Width | 1-11/16 in |
| Precision Vial Properties | Not Applicable |
| Mount Type | Not Applicable |
| Shape | Straight |
| Vial Shape | Block |
| Vial Graduations | ft, .00024 in |
| Level Orientation | Horizontal |
| Finish | Wrinkle |
| Number of Cross Test Vials | 2 |
| Overall Height | 1-5/8 in |
| Sensitivity | 0.0002 in/ft |
| Calibration Certificate | Not Certified |
| Package Quantity | 1 |
