Contador de horas, 24VCA, 60 Hz, montaje en riel DIN.
| Item | Hour Meter |
|---|---|
| Display Type | Electromechanical |
| For Use With | Commercial, Industrial |
| Reset Type | No Reset |
| Mounting Type | DIN Rail |
| Display Units | Hours, Hundredths |
| Operating Voltage | 24V AC |
| Number of Digits | 7 |
| Bezel Face Shape | Square |
| Bezel Face Size | 1.88 in x 1.88 in |
| Bezel Face Type | Flush Mount |
| Time Range | 0 to 99999.99 |
| Material of Construction | Plastic |
| Length | 2.44 in |
| Input Type | Electrical |
| Elapsed Time To | 99,999.99 |
| Hz | 60 Hz |
| Terminal Type | Screw |
| Temp. Range | -40 to 160 deg F |
| Mounting Method | DIN Rail |
| NEMA Rating | 1 |
| Ambient Temp. Range | -40 to 160 deg F |
| Depth | 2.36 in |
| Width | 1.89 in |
| Bezel To Back Length | 2.36 in |
| Length (Straight Wireway) | 2.44 in |
| Character Height | 0.16 in, 4.1 mm |
| Power Required | 1 VA |
| IP Rating | IP20 |
| Standards | cCSAus, CE, RoHS, RU |
| Height | 2.44 in, 62 mm |
| Wiring Option | Combination 1/4" spade and screw clamp |
| Mounting Options | DIN Rail |
| Input Voltage Range(s) | 24 VAC, 60 Hz |
| Digits Coloring (Hours) | White on Black |
| Environmental Rating | IP20 |
| Product Width (in) | 1.89 |
| Digits Coloring (Tenths) | Yellow on Black |
| Operating Temperature Max (°F) | 160 |
| Applications | Distribution/Control Panel Monitoring |
| Mechanism Type | Electromechanical |
| Color | Light Gray |
| Mechanical Movement | Synchronous |
| Product Depth (in) | 2.36 |
| Product Height (in) | 2.44 |
| Hour Meter Material | Plastic |
| Operating Temperature Min (°F) | -40 |
| Operating Temperature Max (°F) | 160 |
| Operating Temperature Min (°F) | -40 |
| Overall Diameter | Not Applicable |
| NEMA Enclosure Rating | 1 |
| Overall Width | 1-7/8 in |
| Overall Height | 2-1/2 in |
| Overall Depth | 2-3/8 in |
| Bezel Face Diameter | Not Applicable |
| Input Voltage - Maximum | 24 V AC |
| Display Span - Maximum | 99,999.99 |
| Bezel Face Width | 1-7/8 in |
| Mounting Style | Flush |
| Operating Temperature - Maximum | 160 deg F |
| Mount Securing Method | DIN Rail |
| Counter Display Type | Analog |
| Bezel Face Height | 1-7/8 in |
| Operating Temperature - Minimum | -40 deg F |
| Hour Unit Increment | Hundreth |
| Package Quantity | 1 |
