Intermatic T101R3 110V Indoor & Outdoor Timer Switch in Metal Enclosure; Beige
| Commercial / Residential | Commercial; Residential |
|---|---|
| Height | 10-1/8 in |
| Length | 3-5/8 in |
| Width | 6-1/2 in |
| Standards | cCSAus, cULus |
| Application | Heater Thermostat Control; Motor Control; Pump Control |
| Motor Load Ratings | 2 HP, 24 FLA @ 120V AC, 60 Hz; 5 HP, 28 FLA @ 240V AC, 60 Hz |
| Input Voltage | 120V AC |
| Switch Type | SPST |
| Hz | 60 |
| Heater Control Output | 10A, 250V AC MAX, 60 Hz |
| Wiring Type | Terminals |
| Tungsten Load Ratings | 40A (120V AC, 60 Hz; 208V AC, 60 Hz; 240V AC, 60 Hz) |
| Pilot Duty Load Ratings | 1000 VA, 120-240V AC, 60 Hz |
| Enclosure Type | Outdoor Type 3R Metal |
| Knockout Dimensions | 1/2 in, 3/4 in |
| Electronic Ballast Load Rating | 16A, 120V AC |
| Min. Operating Temperature | -40°F |
| Number of Circuits | 1 |
| Operation Mode | 24 hr |
| Power Consumption | 3W |
| Inductive Load Ratings | 40A |
| Resistive Load Ratings | 40A (240V AC, 60 Hz; 208V AC, 60 Hz; 120V AC, 60 Hz) |
| Max. Operating Temperature | 54°F |
| Maximum On/Off Operations | 12 |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
