Takes 6 Inserts, 0/90° Lead Angle, 2" High, HP AD.. 1906 Insert Style, Series Heliplus
| Maximum Cutting Diameter (Inch) | 3 |
|---|---|
| Maximum Cutting Diameter (Decimal Inch) | 3.0000 |
| Maximum Depth of Cut (Decimal Inch) | 0.7090 |
| Arbor Hole Diameter (Decimal Inch) | 0.7090 |
| Compatible Insert Size Code | HP AD 1906 |
| Cutter Style | HP F90AT-19 |
| Insert Holding Method | Screw; Clamp |
| Lead Angle | 0/90 |
| Series | Heliplus |
| Maximum Ramping Angle | 2.50 |
| Overall Height (Decimal Inch) | 2.0000 |
| Hub Diameter (mm) | 2.33 |
| Standards | ISO |
| Cutting Edge Length (Decimal Inch) | 0.7090 |
| Minimum Insert Radius (Decimal Inch) | 0.0160 |
| Complete Insert Compatibility | HP ADCR 1906; HP ADKT/ADCT 1906 |
| UNSPSC Code | 27112803 |
| Maximum Insert Radius (Decimal Inch) | 0.1570 |
| Coolant Through | No |
| Number Of Cutter Inserts | 6 |
| Number Of Flutes | 6 |
| Country of Origin | Israel |
| MSC Number | MSC# 45757564 |
