Takes 4 Inserts, 90° Lead Angle, 2-1/4" High, HSM90S APCR 1405.. Insert Style, Through Coolant
| Maximum Cutting Diameter (Inch) | 3 |
|---|---|
| Maximum Cutting Diameter (Decimal Inch) | 3.0000 |
| Maximum Depth of Cut (Decimal Inch) | 0.3940 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Compatible Insert Size Code | HSM90S APCR 1405 |
| Cutter Style | HSM90S FAL |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw; Clamp |
| Lead Angle | 90 |
| Series | Helialu |
| Maximum Ramping Angle | 7.50 |
| Overall Height (Decimal Inch) | 2.2500 |
| Keyway Width (Decimal Inch) | 0.3750 |
| Hub Diameter (Decimal Inch) | 2.1650 |
| Standards | ISO |
| Counterbore Diameter (Decimal Inch) | 0.7800 |
| Complete Insert Compatibility | HSM90S APCR 140532R-P; HSM90S APCR 140508R-P; HSM90S APCR 140516R-P; HSM90S APCR 140540R-P; HSM90S APCR 140530R-P; HSM90S APCR 140520R-P; HSM90S APCR 140550R-P |
| UNSPSC Code | 27112803 |
| Keyway Depth (Decimal Inch) | 0.2190 |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 4 |
| Number Of Flutes | 4 |
| Country of Origin | Israel |
| undefined | undefined |
| MSC Number | MSC# 50099365 |
