Screw, Uses 2 Inserts, LNET Inserts, 4 Tooth
| Connection Type | Modular |
|---|---|
| Maximum Depth of Cut (Decimal Inch) | 0.3660 |
| Maximum Depth of Cut (mm) | 9.30 |
| Hole Diameter (Decimal Inch) | 0.5120 |
| Cutter Diameter (Decimal Inch) | 1.2600 |
| Cutter Diameter (mm) | 32.00 |
| Shank Diameter (mm) | 13.00 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 2 |
| Compatible Insert Style | LNET |
| Compatible Insert Size Code | 082604 |
| Series | ETS-LN08-M |
| Toolholder Style | ETS-LN08-M |
| Hub Diameter (Decimal Inch) | 0.5120 |
| Hub Diameter (mm) | 13.00 |
| Cutting Radius (Fractional Inch) | 1/64 |
| Tool Application | Milling |
| Minimum Cutting Width (Decimal Inch) | 0.1575 |
| Maximum Cutting Width (Decimal Inch) | 0.1770 |
| Maximum Cutting Width (mm) | 4.50 |
| Minimum Cutting Diameter (mm) | 32.00 |
| UNSPSC Code | 23241629 |
| Manufacturers Catalog Number | ETS D032-04-LN08-M08 |
| Overall Height (Decimal Inch) | 30.50 |
| Insert Inscribed Circle (mm) | 6.85 |
| Number Of Teeth | 4 |
| Complete Insert Compatibility | LNET 082604-TN-N |
| Country of Origin | Israel |
| MSC Number | MSC# 45387198 |
